Permit Details

New Residential Construction Permit

Address	4238 SW STATE ROAD 247 LAKE CITY, FL 32024
Parcel #:	03046-003
Acres:	1.02
Owner:	Buchner Ronald,
Subdivision:
Zoning:	RR
Flood Zone:	X
District:	3

Application #:	61584
Permit #:	000047626
Related Permit:
Submitted:	Thursday, June 15, 2023
Issued:	Monday, July 10, 2023
Expires:	Monday, December 11, 2023
Completed:	Monday, December 11, 2023
Status:	Completed
Septic Release?	Yes

Notes:
MFE TO BE 12" ABOVE ADJACENT GRADE FOR ENTIRE PERMIETER OF STRUCTURE

Job Details

This is the construction of a	Single Family Dwelling
Heated Area (Sqft)	900
Total Area (Sqft)	1319
Stories	1
Building Height	14
Building Code Construction Type	V
Building Code Element	B
Building Code Occupancy Types	Residential
Occupancy Use Title	single family dwelling
Setbacks Front	25
Setback Side 1	10
Setback Side 2	10
Setbacks Rear	15
Septic# (00-0000) or (X00-000)	23-0419
Building Code Edition	2020 Florida Building Code 7th Edition and 2017 National Electrical Code
Elevation regulation	Engineers Elevation Letter
Finished floor requirement	12" ABOVE ADJACENT GRADE FOR ENTIRE PERMIETER OF STRUCTURE
Fema map number	12023C0289D
In floodway	N
Sealed roof decking options. (Must select one option per FBC 2023 8th Edition)	a minimum 4-inch wide strip of selfadhering polymer-modified bitumen complying with ASTM D1970 or a minimum 3 ¾ - inch wide strip of selfadhering flexible flashing tape complying with AAMA 711, applied over all joints in the roof decking. A felt underlayment complying with ASTM D226 Type II, ASTM D4869 Type Ill or IV, or ASTM D6757, or a synthetic underlayment meeting the performance requirements specified, is required to be applied over the strips/tape over the entire roof.

Review Notes

6/15/2023	Point Review - Reviewed
6/22/2023	Plan Review - Corrections Needed NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Building Approved NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Electrical Approved NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Mechanical Approved NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Plumbing Approved NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Fuel/Gas Approved NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/22/2023	Plan Review - Reviewed NEEDED *MANUAL J NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW)AA EXISTING STATE ROAD DRIVEWAY APPROVAL - CONTACT D.O.T * ENVIRONMENTAL HEALTH SIGNED SITE PLAN - CONTACT 386-758-1058
6/27/2023	Zoning Review - Reviewed NEEDED
6/27/2023	Final Review - Processing NEEDED
6/27/2023	Zoning Review - Reviewed
7/10/2023	Final Review - Reviewed
7/10/2023	Final Review - Payment Needed
7/10/2023	Permit Issued Permit #000047626 created and approved.

Contractors

This is an owner builder project.

Name/ Business	License	Title	Role
Everton D Ruddock D&s Lighting Inc	EC13003800	Electrical Contractor	Subcontractor

Inspections

Inspection	Notes	Performed By	Date
Passed: Electrical - Temporary Service		Matt Forsyth	7/18/2023
Release to power company		Matt Forsyth	7/18/2023
Passed: Plumbing/Gas - 1st Underground Rough–In		Matt Forsyth	7/18/2023
Passed: Building - Monolithic Slab		Matt Forsyth	7/24/2023
Passed: Engineering - Setbacks		Matt Forsyth	7/24/2023
Passed: Building - Wall Sheathing		Matt Forsyth	8/10/2023
Passed: Building - Framing	Attic Access Not Framed. Post Base All Nail Holes With 16 Penny Nails	Matt Forsyth	9/5/2023
Passed: Building - Roof Decking		Matt Forsyth	9/5/2023
Passed: Building - Strapping	Strapping Installed Inside Sheathing On Gables	Matt Forsyth	9/5/2023
Passed: Electrical - 2nd Rough-In		Troy Crews	10/13/2023
Passed: Mechanical - Rough In		Troy Crews	10/13/2023
Passed: Plumbing/Gas - 2nd Rough-In		Troy Crews	10/13/2023
Passed: Building - Insulation	Walls Only	Matt Forsyth	10/17/2023
Septic Release Inspection		Health Dept	11/7/2023
Passed: Electrical - Permanent Power		Matt Forsyth	11/9/2023
Release to power company		Matt Forsyth	11/9/2023
Passed: Plumbing/Gas - Tub Set/Shower Pan		Matt Forsyth	11/9/2023
Passed: Building - Final	Working On Blower Door And Final Termite Treatment	Matt Forsyth	12/8/2023
Certificate-Release Certificate	All Doc Rec	Matt Forsyth	12/11/2023

Documents

File Name	Date	File Size
Owner And Contractor Signature Page 20230710 031449.pdf	2023.12.23	443.56kB
Owner Disclosure Statement 20230710 031448.pdf	2023.12.23	1.12MB
Win_20230724_11_13_56_pro 2023-07-24 13.31.55.311.jpg	2023.12.23	156.39kB
Win_20230724_10_35_21_pro 2023-07-24 11.15.21.396.jpg	2023.12.23	182.66kB
Manual J & Energy Code.pdf	2023.12.23	8.60MB
Win_20231211_14_03_31_pro 2023-12-11 14.18.47.492.jpg	2023.12.23	128.87kB
Elevation Certificate For Finished Construction 20230710 031848.pdf	2023.12.23	14.14MB
Sealed Modular Plans 20230710 032948.pdf	2023.12.23	10.24MB
Sealed Modular Plans 20230710 032647.pdf	2023.12.23	760.83kB
Win_20231211_14_03_31_pro 2023-12-11 14.22.26.726.jpg	2023.12.23	128.87kB
Energy Code Forms 20230710 031747.pdf	2023.12.23	1.53MB
Power Release-electrical-temporary Service 20230718.pdf	2023.12.23	38.71kB
Product Approval Code Specifications Form 20230710 031948.pdf	2023.12.23	13.62MB
Win_20230724_11_13_56_pro 2023-07-24 11.15.31.146.jpg	2023.12.23	156.39kB
Roof Inspection Affidavit By Contractor 20230710 031647.pdf	2023.12.23	296.28kB
Property Appraiser Parcel Details Printed Page 20230710 031547.pdf	2023.12.23	352.89kB
Engineer Elevation Letter.pdf	2023.12.23	2.65MB
Site Plan 20230710 031749.pdf	2023.12.23	297.39kB
Deed Prior To Zoning Application 61584 2023-06-27 07.38.54.891.pdf	2023.12.23	188.95kB
Noc 2023-07-17 08.04.15.507.pdf	2023.12.23	732.64kB
Application Information Page 20230710 031347.pdf	2023.12.23	342.11kB
Property Appraiser Parcel Details Printed Page 20230710 031548.pdf	2023.12.23	355.49kB
911 Address Form 20230710 031447.pdf	2023.12.23	275.72kB
Truss Engineering 20230710 032355.pdf	2023.12.23	6.10MB
Certificate Of Occupancy 20231211.pdf	2023.12.23	68.94kB
Site Plan 20230626 014347.pdf	2023.12.23	298.60kB
Lidar 61584 2023-06-27 09.07.23.760.pdf	2023.12.23	240.94kB
247 2023-12-11 14.26.36.861.jpg	2023.12.23	3.56MB
Win_20231211_14_03_32_pro 2023-12-11 14.18.03.508.jpg	2023.12.23	84.67kB
New Well Letter 20230710 031648.pdf	2023.12.23	243.22kB
Dot Access 2023-06-23 14.38.41.191.pdf	2023.12.23	185.74kB
Recorded Deed 20230710 031448.pdf	2023.12.23	522.71kB
Truss Engineering 20230710 040947.pdf	2023.12.23	5.44MB
Residential Or Commercial Checklist 20230710 031648.pdf	2023.12.23	1.92MB
Original Permit 20230710.pdf	2023.12.23	135.26kB
Power Release-electrical-permanent Power 20231109.pdf	2023.12.23	38.84kB
Subcontractor Form 20230710 031748.pdf	2023.12.23	344.63kB
Env Health 2023-06-23 14.47.58.112.pdf	2023.12.23	1.43MB
