Failed: Mechanical - Rough In
Kitchen Hood Not Completed, Master Exhaust Venting Not Strapped Up. Return In Laundry No Required.
m1602.3balanced Return Air.
restricted Return Air Occurs In Buildings When Returns Are Located In Central Zones And Closed Interior Doors Impede Air Flow To The Return Grill Or When Ceiling Spaces Are Used As Return Plenums And Fire Walls Restrict Air Movement From One Portion Of The Return Plenum To Another. Provisions Shall Be Made In Both Residential And Commercial Buildings To Avoid Unbalanced Air Flows And Pressure Differentials Caused By Restricted Return Air. Pressure Differentials Across Closed Doors Where Returns Are Centrally Located Shall Be Limited To 0.01 Inch W.c. (2.5 Pa) Or Less. Pressure Differentials Across Fire Walls In Ceiling Space Plenums Shall Be Limited To 0.01 Inch W.c. (2.5 Pa) By Providing Air Duct Pathways Or Air Transfer Pathways From The High Pressure Zone To The Low Zone.
exceptions:
1.transfer Ducts May Achieve This By Increasing The Return Transfer 11/2 Times The Cross Sectional Area (square Inches) Of The Supply Duct Entering The Room Or Space It Is Serving And The Door Having At Least An Unrestricted 1-inch Undercut To Achieve Proper Return Air Balance.
2.transfer Grilles Shall Use 50 Square Inches (of Grille Area) To 100 Cfm (of Supply Air) For Sizing Throughthe-wall Transfer Grilles And Using An Unrestricted 1-inch Undercutting Of Doors To Achieve Proper Return Air Balance.
3.habitable Rooms Only Shall Be Required To Meet These Requirements For Proper Balanced Return Air Excluding Bathrooms, Closets, Storage Rooms And Laundry Rooms, Except That All Supply Air Into The Master Suite Shall Be Included.
Inspected by Anthony Aslan
