Permit Details

New Residential Construction Permit

Address	485 SW JOE MARKHAM DR LAKE CITY, FL 32024
Parcel #:	00469-105
Acres:	10.00
Owner:	Tovar Argel Mancilla, Tovar Mercedes Del Carmen Mancilla
Subdivision:	Shirley Gorospe Tract (division Of Land)
Zoning:	ESA-2
Flood Zone:	X
District:	2

Application #:	62162
Permit #:	000048086
Related Permit:	Culvert Waiver: 000048085
Submitted:	Tuesday, August 8, 2023
Issued:	Tuesday, September 12, 2023
Expires:	Wednesday, March 20, 2024
Completed:	Wednesday, March 20, 2024
Status:	Completed
Septic Release?	Yes

Notes:
MFE 1' ABOVE THE ROAD

Job Details

This is the construction of a	Single Family Dwelling
Heated Area (Sqft)	2019
Total Area (Sqft)	2400
Stories	1
Building Height	20
Building Code Construction Type	V
Building Code Element	B
Building Code Occupancy Types	Residential
Occupancy Use Title	single family dwelling
Setbacks Front	30'
Setback Side 1	25'
Setback Side 2	25'
Setbacks Rear	25'
Septic# (00-0000) or (X00-000)	23-0584
Service Amps	200
Building Code Edition	2020 Florida Building Code 7th Edition and 2017 National Electrical Code
Elevation regulation	Minimum Requirement
Finished floor requirement	One foot above the road
Fema map number	12023C0370C
In floodway	N
Sealed roof decking options. (Must select one option per FBC 2023 8th Edition)	two layers of felt underlayment comply ASTM 0226 Type II or ASTM D4869 Type Ill or IV, or two layers of a synthetic underlayment meeting the performance requirements specified, lapped and fastened as specified.

Review Notes

8/8/2023	Application pending.
8/8/2023	Application submitted by applicant.
8/16/2023	Point Review - Printed-Online Application NEEDED * 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/16/2023	Point Review - Reviewed NEEDED * 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Corrections Needed NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Building Approved NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Electrical Approved NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Mechanical Approved NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Plumbing Approved NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Fuel/Gas Approved NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/18/2023	Plan Review - Reviewed NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN
8/22/2023	Zoning Review - Reviewed NEEDED *ENERGY FORM NOT SEER2 COMPLIANT (NEED BY FINAL REVIEW) 911 ADDRESS * ENVIRONMENTAL HEALTH SIGNED SITE PLAN * MFE 1' ABOVE THE ROAD
9/12/2023	Final Review - Reviewed * MFE 1' ABOVE THE ROAD
9/12/2023	Final Review - Payment Needed * MFE 1' ABOVE THE ROAD
9/12/2023	Permit Issued Permit #000048086 created and approved.
2/5/2024	Final Review - Payment Needed * MFE 1' ABOVE THE ROAD

Contractors

Name/ Business	License	Title	Role
Tabitha M Sibel Rjh Construction County License & State License & Liability Insurance & Workers Comp & Employees Workers Comp Expired.	CGC1515388	General Contractor	Contractor
Cody Barrs Barrs Plumbing Inc	CFC1427145	Plumbing Contractor	Subcontractor
Robert Lynch Third Day Electric Llc	EC13001947	Cert. Electrical	Subcontractor
Timothy D Shatto Shatto Heating & Air, Inc.	CAC057875	A/c Class B	Subcontractor
Tabitha M Sibel Rjh Construction County License & State License & Liability Insurance & Workers Comp & Employees Workers Comp Expired.	CCC1331967	Cert. Roofing	Subcontractor

Inspections

Inspection	Notes	Performed By	Date
Passed: Building - Footer		Matt Forsyth	9/25/2023
Passed: Engineering - Setbacks		Matt Forsyth	9/25/2023
Passed: Plumbing/Gas - 1st Underground Rough–In		Matt Forsyth	11/1/2023
Passed: Building - Footer	Monolithic Slab	Matt Forsyth	11/9/2023
Passed: Engineering - Setbacks		Matt Forsyth	11/9/2023
Passed: Building - Slab	Monolithic Slab	Matt Forsyth	11/9/2023
Passed: Building - Ext Strapping/Wall Sheathing		Matt Forsyth	11/29/2023
Passed: Building - Roof Decking		Matt Forsyth	11/29/2023
Cancelled: Building - Roof Decking		Matt Forsyth	12/6/2023
Passed: Building - Framing		Matt Forsyth	12/18/2023
Passed: Electrical - 2nd Rough-In		Matt Forsyth	12/18/2023
Passed: Mechanical - Rough In	Keep Clearances On Your Duckboard To Framing Members	Matt Forsyth	12/18/2023
Passed: Plumbing/Gas - 2nd Rough-In	Shower Floor Inspection Needed And All Water And Tubs Tested	Matt Forsyth	12/18/2023
Passed: Building - Insulation		Matt Forsyth	1/5/2024
Passed: Electrical - Permanent Power	Need Septic	Matt Forsyth	2/6/2024
Release to power company	Rec'd Septic	Matt Forsyth	2/21/2024
Septic Release Inspection		Health Dept	2/21/2024
Failed: Building - Final	No Disconnect On Air Handler Electrical Panel Box Needs To Be Relabeled	Matt Forsyth	3/18/2024
Passed: Building - Final		Matt Forsyth	3/20/2024

Documents

File Name	Date	File Size
Certificate Of Occupancy 20240320.pdf	2024.03.20	69.45kB
Win_20240318_16_07_10_pro 2024-03-18 16.08.11.751.jpg	2024.03.18	212.14kB
Power Release-release To Power Company 20240221.pdf	2024.02.21	38.92kB
Property Appraiser Parcel Details Printed Page 20230808 134238.pdf	2023.12.23	862.70kB
Residential Or Commercial Checklist 20230808 134238.pdf	2023.12.23	857.30kB
Lidar 62162 2023-08-22 14.08.26.480.pdf	2023.12.23	361.01kB
Reviewed Truss Engineering 62162 2023-08-18 12.19.04.698.pdf	2023.12.23	1.90MB
Recorded Deed 20230808 133301.pdf	2023.12.23	147.84kB
Owner And Contractor Signature Page 20230808 133301.pdf	2023.12.23	210.85kB
Original Permit 20230912.pdf	2023.12.23	46.15kB
Win_20231109_15_37_52_pro 2023-11-09 15.38.11.189.jpg	2023.12.23	226.52kB
911 Address Form 20230823 135709.pdf	2023.12.23	256.96kB
485 Sw Joe Markham Dr.pdf	2023.12.23	844.55kB
Product Approval Code Specifications Form 20230808 135604.pdf	2023.12.23	133.47kB
Reviewed Architectural Plans 62162 2023-08-18 12.21.12.647.pdf	2023.12.23	7.15MB
Manual J Forms 20230825 165906.pdf	2023.12.23	431.00kB
Recorded Notice Of Commencement 20230808 134238.pdf	2023.12.23	133.78kB
Structural Engineering And Wind Load Calculations 20230815 124331.pdf	2023.12.23	6.09MB
Subcontractor Form 20230808 134240.pdf	2023.12.23	650.04kB
Manual J Forms 20230808 134237.pdf	2023.12.23	353.52kB
Site Plan 20230808 134239.pdf	2023.12.23	70.72kB
Energy Code Forms 20230808 134237.pdf	2023.12.23	228.49kB
Reviewed S.3.pdf	2023.12.23	2.45MB
Septic Approval Paperwork 20230901 125738.pdf	2023.12.23	1.01MB
Reviewed S.2.pdf	2023.12.23	1.17MB
Reviewed S.1.pdf	2023.12.23	1,010.92kB
