Permit Details

New Residential Construction Permit

Address	170 SW GUINEVERE WAY LAKE CITY, FL 32024
Parcel #:	03099-208
Acres:	0.51
Owner:	Roberts Michael
Subdivision:	Stonehenge Phase 2
Zoning:	RSF-2
Flood Zone:	X
District:	3

Application #:	56611
Permit #:	000045726
Related Permit:	Culvert: 000045727
Submitted:	Tuesday, September 27, 2022
Issued:	Thursday, December 15, 2022
Expires:	Monday, July 24, 2023
Completed:	Monday, July 24, 2023
Status:	Completed
Septic Release?	Yes

Notes:
*SURVEYOR TO CONFIRM ELEVATION
LAKE CITY UTLITY CUSTOMER SERVICE NOTES The Utility Department approved the tap application for water service. The utility fees were paid on 01/24/23.

Job Details

This is the construction of a	Single Family Dwelling
Heated Area (Sqft)	1761.1
Total Area (Sqft)	2459.6
Stories	1
Building Height	17
Building Code Construction Type	V
Building Code Element	B
Building Code Occupancy Types	Residential
Occupancy Use Title	single family dwelling
Setbacks Front	25'
Setback Side 1	10'
Setback Side 2	10'
Setbacks Rear	15'
Septic# (00-0000) or (X00-000)	22-0737
Service Amps	200
Building Code Edition	2020 Florida Building Code 7th Edition and 2017 National Electrical Code
Elevation regulation	Engineers Elevation Letter
Finished floor requirement	99.77'
Requirement needed	By Nailing Inspection
Document needed is	a Surveyor letter giving the Finished Floor Elevation
Document receieved	Yes
Fema map number	12023C0289D
In floodway	N
Sealed roof decking options. (Must select one option per FBC 2020 7th Edition)	two layers of felt underlayment comply ASTM 0226 Type II or ASTM D4869 Type Ill or IV, or two layers of a synthetic underlayment meeting the performance requirements specified, lapped and fastened as specified.

Review Notes

9/26/2022	Application pending.
9/27/2022	City of Lake City Notified of Application within Utility Service Areas LC_WATER,.
9/28/2022	Point Review - Printed-Online Application NEEDED: ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058 OWNER AND CONTRACTOR SIGNATURE PAGE
9/28/2022	Point Review - Reviewed NEEDED: ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058 OWNER AND CONTRACTOR SIGNATURE PAGE
10/3/2022	Plan Review - Corrections Needed NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/3/2022	Plan Review - Building Approved NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/3/2022	Plan Review - Electrical Approved NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/3/2022	Plan Review - Mechanical Approved NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/3/2022	Plan Review - Plumbing Approved NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/3/2022	Plan Review - Reviewed NEEDED: *PRODUCT APPROVAL # 8228.1 & 13191.2 NOT CURRENT CODE 2020 ( NEED BY FINAL REVIEW ) ENV HEALTH SIGNED SITE PLAN APPROVAL-- CONTACT 386-758-1058
10/6/2022	Plan Review - Reviewed NEEDED: *ENV HEALTH SIGNED SITE PLAN APPROVAL-- PLEASE UPLOAD THE APPLICATION PAGE WITH THE SIGNED SITE PLAN APPROVAL
10/10/2022	Zoning Review - Reviewed NEEDED: *ENV HEALTH SIGNED SITE PLAN APPROVAL-- PLEASE UPLOAD THE APPLICATION PAGE WITH THE SIGNED SITE PLAN APPROVAL
10/11/2022	Final Review - Reviewed NEEDED:
10/14/2022	Final Review - Reviewed
10/14/2022	Final Review - Payment Needed
10/20/2022	Permit Issued Permit #000045726 created and approved.
12/15/2022	Permit Reissued Permit reissued to reflect updated information.
6/20/2023	Final Review - Payment Needed

Contractors

Name/ Business	License	Title	Role
Sara E Gresham John Norris Construction, Llc	CRC1331978	Cert. Residential	Contractor
Roger Whiddon Lake City Plumbing Inc	CFC1428686	Cert Plumbing	Subcontractor
Robert A Feasel Robbies Roofing Inc	RC29027319	Roofing Contractor	Subcontractor
Marcus Matthews Matthews Electric Llc	EC13005459	Electrical Contractor	Subcontractor
Anthony R Franks Lane Heating & Air Llc	CAC1818631	Cert. A/c Class “b”	Subcontractor

Inspections

Inspection	Notes	Performed By	Date
Passed: Engineering - Initial Driveway		Smith, Blake	10/24/2022
Failed: Electrical - Temporary Service	No Pedestal Found	Matt Forsyth	11/7/2022
Passed: Electrical - Temporary Service		Matt Forsyth	11/7/2022
Release to power company		Matt Forsyth	11/7/2022
Passed: Electrical - 1st Underground Rough–In		Matt Forsyth	11/16/2022
Passed: Building - Monolithic Slab		Matt Forsyth	11/18/2022
Passed: Engineering - Setbacks		Matt Forsyth	11/18/2022
Passed: Building - Roof Decking		Matt Forsyth	12/20/2022
Passed: Building - Wall Sheathing		Matt Forsyth	12/20/2022
Passed: Building - Framing		Matt Forsyth	1/10/2023
Failed: Electrical - 2nd Rough-In	20 Amp Receptacle Required In Garage	Matt Forsyth	1/10/2023
Passed: Mechanical - Rough In		Matt Forsyth	1/10/2023
Passed: Plumbing/Gas - 2nd Rough-In		Matt Forsyth	1/10/2023
Passed: Plumbing/Gas - Tub Set/Shower Pan	Tub Water Tested	Matt Forsyth	1/10/2023
Passed: Building - Insulation		Matt Forsyth	1/18/2023
Passed: Electrical - Permanent Power	Need Septic And Drive Final	Troy Crews	6/21/2023
Release to power company		Melissa Garber	6/23/2023
Passed: Engineering - Final Driveway		Smith, Blake	6/23/2023
Septic Release Inspection		Health Dept	6/23/2023
Certificate-Release Certificate		Matt Forsyth	7/24/2023
Passed: Building - Final	Blower Door Test Dryer Vent Replaced	Matt Forsyth	7/24/2023

Documents

File Name	Date	File Size
Site Plan 20220926 111051.pdf	2023.12.24	293.54kB
Owner And Contractor Signature Page 20220929 194826.pdf	2023.12.24	737.60kB
Power Release-electrical-temporary Service 20221107.pdf	2023.12.24	38.83kB
Energy Code Forms 20220926 111048.pdf	2023.12.24	5.57MB
Subcontractor Form 20220926 111052.pdf	2023.12.24	419.07kB
Manual J Forms 20220926 111050.pdf	2023.12.24	494.92kB
Win_20230724_11_32_06_pro 2023-07-24 11.32.28.604.jpg	2023.12.24	125.76kB
45726 Plans 2022-12-27 13.17.19.306.pdf	2023.12.24	4.49MB
Certificate Of Occupancy 20230724.pdf	2023.12.24	68.96kB
Rviewed Truss Engineering 56611 2022-10-03 09.55.12.618.pdf	2023.12.24	617.74kB
City Of Lake City Approval Letter.pdf	2023.12.24	185.67kB
Updated Permit 20221215.pdf	2023.12.24	113.94kB
Lidar 56611 2022-10-10 11.35.20.03.pdf	2023.12.24	93.67kB
911 Address Form 20220926 111047.pdf	2023.12.24	316.74kB
Property Appraiser Parcel Details Printed Page 20220926 113705.pdf	2023.12.24	380.69kB
Surveyor Letter Giving The Finished Floor Elevation 20221216 020546.pdf	2023.12.24	209.69kB
Product Approval Code Specifications Form 20220926 111050.pdf	2023.12.24	550.70kB
Recorded Notice Of Commencement 20220926 111051.pdf	2023.12.24	516.20kB
Bdt 45726 2023-07-24 15.07.09.773.pdf	2023.12.24	1.47MB
Win_20221118_10_52_51_pro 2022-11-18 10.53.26.376.jpg	2023.12.24	246.48kB
Recorded Deed 20220926 111051.pdf	2023.12.24	375.07kB
Stonehenge_phs2 2022-09-27 16.27.01.152.pdf	2023.12.24	4.59MB
Engineer Letter Ffe Requirement 45726.pdf	2023.12.24	1.86MB
Septic Approval Paperwork 20221013 042847.pdf	2023.12.24	532.86kB
Power Release-release To Power Company 20230623.pdf	2023.12.24	38.97kB
Product Approval Code Specifications Form 20221005 210347.pdf	2023.12.24	455.94kB
Original Permit 20221020.pdf	2023.12.24	113.92kB
Residential Or Commercial Checklist 20220926 113705.pdf	2023.12.24	3.09MB
Truss Engineering 20220926 113606.pdf	2023.12.24	538.98kB
