Permit Details

New Residential Construction Permit

Address	136 SW GRAND MAGNOLIA GLN LAKE CITY, FL 32024
Parcel #:	02439-124
Acres:	0.24
Owner:	Sorensen & Smith Llc
Subdivision:	Reserve At Jewel Lake Phase 1
Zoning:	PRD
Flood Zone:	X
District:	3

Application #:	53465
Permit #:	000043802
Related Permit:
Submitted:	Thursday, February 10, 2022
Issued:	Monday, February 28, 2022
Expires:	Tuesday, August 16, 2022
Completed:	Tuesday, August 16, 2022
Status:	Completed
Septic Release?	No

Notes:
SURVEYOR MUST CONFIRM SETBACKS FINISHED FLOOR 124 FT. ELEVATION CONFIRMATION REC'D @ 127.80'

Job Details

This is the construction of a	Single Family Dwelling
Heated Area (Sqft)	1504
Total Area (Sqft)	2402
Stories	1
Building Height	19.8
Building Code Construction Type	V
Building Code Element	B
Building Code Occupancy Types	Residential
Occupancy Use Title	SINGLE FAMILY DWELLING
Setbacks Front	25'
Setback Side 1	10'
Setback Side 2	10'
Setbacks Rear	15'
Service Amps	200
Building Code Edition	2020 Florida Building Code 7th Edition and 2017 National Electrical Code
Elevation regulation	Subdivision Plat
Finished floor requirement	124'
Requirement needed	By Nailing Inspection
Document needed is	a Surveyor letter giving the Finished Floor Elevation
Document receieved	Yes
Fema map number	12023C0290D
In floodway	N
Sealed roof decking options. (Must select one option per FBC 2020 7th Edition)	two layers of felt underlayment comply ASTM 0226 Type II or ASTM D4869 Type Ill or IV, or two layers of a synthetic underlayment meeting the performance requirements specified, lapped and fastened as specified.

Review Notes

2/10/2022	Application pending.
2/10/2022	City of Lake City City of Lake City Notified of Application within Utility Service Areas LC_WATER, LC_SEWER.
2/13/2022	Point Review - Printed-Online Application
2/13/2022	Point Review - Reviewed
2/21/2022	Plan Review - Corrections Needed *need electricial plan to have current 2017 code
2/24/2022	Plan Review - Building Approved
2/24/2022	Plan Review - Electrical Approved
2/24/2022	Plan Review - Mechanical Approved
2/24/2022	Plan Review - Plumbing Approved
2/24/2022	Plan Review - Reviewed
2/24/2022	Zoning Review - Reviewed
2/28/2022	Final Review - Reviewed
2/28/2022	Final Review - Payment Needed
2/28/2022	Permit Issued Permit #000043802 created and approved.
8/10/2022	Final Review - Payment Needed

Contractors

Name/ Business	License	Title	Role
Gerald M Smith Sr S&s Construction Llc County License & State License & Liability Insurance Expired.	CBC1254161	Building Contractor	Contractor
Daniel Mossburg Live Oak Plumbing, Inc. County License & State License & Liability Insurance & Workers Comp & Employees Workers Comp Expired.	CFC1427438	Plumbing Contractor	Subcontractor
Benjamin T Keeler Keeler Roofing, Llc	CCC1330509	Cert. Roofing	Subcontractor
Lyndon J Rainbolt Rainbolt Tech Services,air Stream County License & State License & Liability Insurance & Workers Comp Expired.	EC13001835	Electrical Contractor	Subcontractor
Arthur (paul) P King Jr Pauls Heating & Air Inc County License & State License & Liability Insurance & Workers Comp & Employees Workers Comp Expired.	CAC1813957	Cert Class B A/c	Subcontractor

Inspections

Inspection	Notes	Performed By	Date
Passed: Building - Footer		Troy Crews	3/30/2022
Passed: Engineering - Setbacks		Troy Crews	3/30/2022
Passed: Plumbing/Gas - 1st Underground Rough–In		Troy Crews	4/13/2022
Passed: Building - Slab		Troy Crews	4/22/2022
Passed: Plumbing/Gas - 2nd Rough-In		Troy Crews	5/11/2022
Passed: Building - Ext Strapping/Wall Sheathing		Troy Crews	5/12/2022
Passed: Building - Framing		Troy Crews	5/12/2022
Passed: Building - Roof Decking		Troy Crews	5/12/2022
Passed: Building - Strapping		Troy Crews	5/12/2022
Cancelled: Building - Wall Sheathing		Troy Crews	5/12/2022
Passed: Electrical - 2nd Rough-In		Troy Crews	5/12/2022
Passed: Mechanical - Rough In		Troy Crews	5/12/2022
Passed: Plumbing/Gas - 2nd Rough-In		Troy Crews	5/12/2022
Passed: Building - Insulation		Troy Crews	5/17/2022
Passed: Electrical - Permanent Power	Have Electrician Safe Off Wires In Kitchen	Troy Crews	6/17/2022
Release to power company		Troy Crews	6/17/2022
Passed: Building - Final		Troy Crews	8/16/2022

Documents

File Name	Date	File Size
Structural Engineering And Wind Load Calculations 20220210 135216.pdf	2023.12.23	782.02kB
Manual J Forms 20220210 135214.pdf	2023.12.23	198.46kB
Architectural Plans 20220221 111915.pdf	2023.12.23	500.59kB
Architectural Plans 20220210 135213.pdf	2023.12.23	863.66kB
Certificate Of Occupancy 20220816.pdf	2023.12.23	54.57kB
City Or County Utility Availability Letter 20220210 151840.pdf	2023.12.23	58.59kB
Blower Door 43802 2022-08-16 13.49.47.904.jpg	2023.12.23	2.01MB
Other 20220210 135214.pdf	2023.12.23	20.76kB
Approved Structural Engineering And Wind Load Calculations 53465 2022-02-21 10.50.02.512.pdf	2023.12.23	826.68kB
Truss Engineering.pdf	2023.12.23	1.38MB
Approved Architectural Plans 53465 2022-02-24 12.27.16.891.pdf	2023.12.23	519.96kB
Property Appraiser Parcel Details Printed Page 20220210 135215.pdf	2023.12.23	119.30kB
Reserve At Jewel Lake (2017) (2) 2022-02-13 12.00.02.903.pdf	2023.12.23	10.62MB
Subcontractor Form 20220210 135216.pdf	2023.12.23	111.33kB
Lidar 53465 2022-02-24 15.34.00.260.pdf	2023.12.23	67.92kB
Product Approval Code Specifications Form 20220210 135214.pdf	2023.12.23	150.76kB
Surveyor Letter Giving The Finished Floor Elevation 43802.pdf	2023.12.23	233.39kB
Approved Truss Engineering 53465 2022-02-21 10.50.01.918.pdf	2023.12.23	1.46MB
Owner And Contractor Signature Page 20220210 131723.pdf	2023.12.23	122.51kB
Recorded Deed 20220210 131723.pdf	2023.12.23	72.69kB
Energy Code Forms 20220210 135214.pdf	2023.12.23	216.87kB
Power Release-electrical-permanent Power 20220617.pdf	2023.12.23	38.79kB
Win_20220422_10_57_24_pro 2022-04-22 10.58.03.384.jpg	2023.12.23	301.37kB
911 Address Form 20220210 135212.pdf	2023.12.23	63.12kB
Corporate Articles Listing The Owner Or Poa Form Or Executor Documents 20220210 135213.pdf	2023.12.23	67.37kB
Subcontractor Form 20220315 054747.pdf	2023.12.23	327.35kB
Recorded Notice Of Commencement 20220210 135215.pdf	2023.12.23	111.32kB
Residential Or Commercial Checklist 20220210 135215.pdf	2023.12.23	773.54kB
Site Plan 20220210 135216.pdf	2023.12.23	46.41kB
Original Permit 20220228.pdf	2023.12.23	45.74kB
